MPAD Spirit A1
Promotion UV Flatbed Printer
All the flat materials: glass, ceramic, ceiling aluminum sheet, wood board, door sheet, metal panel, billboard; pvc, adhesive back vinyls, fabrics canvas, carpet, glisten film etc.
Specifications
Spirit A1
Color Mode
2(C M Y K)+4W+4V
Dimension (mm)
1650*1000*900mm
Durability
Outdoor: 3 years / Indoor: 7 years
File Format
TIFF, JPEG, BMP, EPS and PDF
Gross Weight
300KGS
Humidity
40%-60%
Ink Supply System
Refillable Ink Cartridge
Max Resolution
2880DPI
Media Thickness
80mm
Operation Environment
(Temperature) 20 to 28 degrees
Packing Size
1800*1150*1000mm
PH Height Adjustment
Motor control
Power Supply
50/60Hz, AC 220V (10%), 800W
Print Head Type
Epson DX7
Print Size
60x90mm
Printhead Maintenance
Auto Cleaning
Rip Software
Photoprint 10.5
Speed Draft Mode
7 sqm/h @ 360*1440dpi
Speed Fine Mode
2 sqm/h @ 720*2880dpi
Speed High Quality Mode
3 sqm/h @ 360*2880dpi
Speed Production Mode
5 sqm/h @ 720*1440dpi
Table Type
Vacuum Table
UV Curing System
LED Water Cooling System
